Smooth line technology brings new style lighting that
instead of using COB LED strips
Flexible chip-on-FPC strip with uniform and soft light, good linearity,
no glare, high color consistency, with the controller can achieve light brightness control.
Through the control of lighting dynamic effect, it can adapt to different scene application,
making immersive feeling.
GOOD BENDABILITY
High-end vapor phase silicone, good softness and plasticity.
IP67 WATERPROOF
SMD strip light with silicone extrusion process, providing excellent sealing performance.
| Model | Wave Length CCT Range(for LED only) | Lumen (lm/m) | CRI | LED Type | LED Qty. (PCS/M) | DC Voltage(V) | Rated Watt(w/m) | Beam Angle | IP |
| SC-2835-07-JT1006W-XX-24-238-8-IP67 | 2800-3200K | 1380 | 80 | 2835 | 238 | 24 | 15 | 150° | 67 |
| 3800-4500K | 1560 | ||||||||
| 6000-6500K | 1600 | ||||||||
| SC-2835-07-JT1006W-XXST-24-238-8-IP67 | 2800-3200K | 1850 | 80 | 2835 | 238 | 24 | 15 | 150° | 67 |
| 3800-4500K | 1950 | ||||||||
| 6000-6500K | 2000 | ||||||||
| SC-2835-07-JT1006W-XXST-24-238-8-IP67 | 6000K-6500K | 1600 | 70 | 3528 | 252 | 24 | 15 | 150° | 67 |
| SC-3528-14-JT1006W-23K80-24-252-8-IP67 | 2200K-2500K | 1300 | 80 | ||||||
| SC-3528-14-JT1006W-23K90-24-252-8-IP67 | 2200K-2500K | 1100 | 90 | ||||||
| SC-3528-14-JT1006W-30K90-24-252-8-IP67 | 2800K-3200K | 1200 | 90 | ||||||
| SC-3014-07-JT1006W-23K80-24-350-8-IP67 | 2200K-2500K | 950 | 80 | 3014 | 350 | 24 | 15 | 150° | 67 |
| SC-3014-07-JT1006W-40K80-24-350-8-IP67 | 3800K-4500K | 1200 | 80 | ||||||
| SC-3014-07-JT1006W-22K90-24-350-8-IP67 | 2200K-2500K | 800 | 90 | ||||||
| SC-3014-07-JT1006W-30K-24-350-8-IP67 | 2800K-3200K | 900 | 90 |
Unit: mm/inch
