Ultra-narrow
Dimension: 6×6mm,suitable for ultra-narrow spaces
Soft Light
More uniform luminescence. No light dot can be seen even in close distance，soft light.
Good flexibility and plasticity
High-end vapor phase silicone, strong weather resistance, no yellowing, good softness and plasticity.
Waterproof and safer application
The product has passed CE, RoHS and other certifications, good waterproof effect, safer application.
| Model | CCT | Luminous Flux (lm/M) | LED Type | LED Qty. (PCS/M) | DC Voltage(V) | Beam angle | PCB Width(mm) | Rated Watt(w/m) | IP | Ra |
| SC-3014-07-TT0606W -XX-24-210-4-IP65 | 2800-3200K | 654 | 3014 | 210 | 24 | 113° | 4 | 7.2 | 65 | 80 |
| 3800-4500K | 673 | |||||||||
| 6000-6500K | 705 | |||||||||
| Red | / | 3014 | 210 | 24 | 113° | 4 | 7.2 | 65 | / | |
| Green | / | |||||||||
| Blue | / |
Unit: mm/inch
