The line uses two bare DIP switches to adjust for 5 CCT and 3 power applications. The 0-10 volt control offers remote J-box dimming compatibility for easy installation in existing recessed areas.
The frame does not require a separate shell, and the recessed jig is mounted directly onto the ceiling.
Achieve selection of five types of color temperature through five-section dip switches.
Long service life: the adoption of LEDs ensures that the service life exceeds 50000 hours.
Compatible with most dimmers of North American to obtain good dimming effect.
Tpye-IC rated and suitable for wet location applications.
Coming soon, please wait... |
| Model | CCT | Lumen(lm±10%) | Beam(angle) | LED Type | LED Qty. | Power(w) (±10%) | Voltage | CRI | PF |
| DL214 series 4inch | 2700K | 600 | 95 | 2835 | 14 | 10W | AC120V 60Hz | ≥90 | >0.8 |
| 3000K | 620 | ||||||||
| 3500K | 700 | ||||||||
| 4000K | 700 | ||||||||
| 5000K | 650 | ||||||||
| DL214 series 6inch | 2700K | 900 | 95 | 2835 | 14 | 15W | AC120V 60Hz | ≥90 | >0.8 |
| 3000K | 950 | ||||||||
| 3500K | 1000 | ||||||||
| 4000K | 1000 | ||||||||
| 5000K | 950 | ||||||||
DL214 series 8inch | 2700K | 1600 | 95 | 2835 | 28 | 25W | AC120V 60Hz | ≥90 | >0.8 |
| 3000K | 1600 | ||||||||
| 3500K | 1750 | ||||||||
| 4000K | 1750 | ||||||||
| 5000K | 1600 | ||||||||
| DL214 series 10inch | 2700K | 1900 | 95 | 2835 | 28 | 30W | AC120V 60Hz | ≥90 | >0.8 |
| 3000K | 1900 | ||||||||
| 3500K | 2000 | ||||||||
| 4000K | 2000 | ||||||||
| 5000K | 1900 |
