Sl8456 linear light is combination of separated structures, it is convenient to dismantle and maintain because of its replaceable power supply and lighting emitting parts(PCB+LEDs), simple shape and random jointing can be realized.
Multiple jointing can realized via "L" shape connecting accessories.
The product can operate in single run or continuous runs seamless, when input voltage is AC220V, 900W can be connected; when input voltage is 110V, 450W can be connected.
The lamp and power supply is connected with high-voltage live part via connector; it is very convenient to install and disassemble, and it is also safe and reliable to use.
PC diffusor and Al6063 aluminum profile, with good heat distribution and high light efficiency.
With 30% indirect and 70% direct lighting.
| Model | CCT | Lumen(lm) (±10%) | LED type | LED qty. | Power(W) (±10%) | Length(mm) | Voltage (V) | CRI | Beam angle | Dimming options |
| SC-SL8456-040-UD-AW-CW | 6000K-6500K | 4100 | 2835 | 252 | 40W | 1200 | 200-240VA C50/60Hz | >80 | 110° | No dimming |
| SC-SL8456-040-UD-AW-NW | 3800K-4200K | 4200 | ||||||||
| SC-SL8456-040-UD-AW-WW | 2800K-3200K | 4000 | ||||||||
| SC-SL8456-050-UD-AW-CW | 6000K-6500K | 5100 | 2835 | 322 | 50W | 1500 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-050-UD-AW-NW | 3800K-4200K | 5200 | ||||||||
| SC-SL8456-050-UD-AW-WW | 2800K-3200K | 5000 | ||||||||
| SC-SL8456-080-UD-AW-CW | 6000K-6500K | 8200 | 2835 | 504 | 80W | 2400 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-080-UD-AW-NW | 3800K-4200K | 8400 | ||||||||
| SC-SL8456-080-UD-AW-WW | 2800K-3200K | 8000 | ||||||||
| SC-SL8456L-040-UD-AW-CW | 6000K-6500K | 4100 | 2835 | 252 | 40W | L-shape | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456L-040-UD-AW-NW | 3800K-4200K | 4200 | ||||||||
| SC-SL8456L-040-UD-AW-WW | 2800K-3200K | 4000 | ||||||||
| SC-SL8456-040-UD-DA-AW-CW | 6000K-6500K | 4100 | 2835 | 252 | 40W | 1200 | 200-240VA C50/60Hz | >80 | 110° | DALI dimming |
| SC-SL8456-040-UD-DA-AW-NW | 3800K-4200K | 4200 | ||||||||
| SC-SL8456-040-UD-DA-AW-WW | 2800K-3200K | 4000 | ||||||||
| SC-SL8456-050-UD-DA-AW-CW | 6000K-6500K | 5100 | 2835 | 322 | 50W | 1500 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-050-UD-DA-AW-NW | 3800K-4200K | 5200 | ||||||||
| SC-SL8456-050-UD-DA-AW-WW | 2800K-3200K | 5000 | ||||||||
| SC-SL8456-080-UD-DA-AW-CW | 6000K-6500K | 8200 | 2835 | 504 | 80W | 2400 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-080-UD-DA-AW-NW | 3800K-4200K | 8400 | ||||||||
| SC-SL8456-080-UD-DA-AW-WW | 2800K-3200K | 8000 | ||||||||
| SC-SL8456L-040-UD-DA-AW-CW | 6000K-6500K | 4100 | 2835 | 252 | 40W | L-shape | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456L-040-UD-DA-AW-NW | 3800K-4200K | 4200 | ||||||||
| SC-SL8456L-040-UD-DA-AW-WW | 2800K-3200K | 4000 | ||||||||
| SC-SL8456-040-UD-EM-AW-CW | 6000K-6500K | 4100 | 2835 | 252 | 40W | 1200 | 200-240VA C50/60Hz | >80 | 110° | Emergency + No dimming |
| SC-SL8456-040-UD-EM-AW-NW | 3800K-4200K | 4200 | ||||||||
| SC-SL8456-040-UD-EM-AW-WW | 2800K-3200K | 4000 | ||||||||
| SC-SL8456-050-UD-EM-AW-CW | 6000K-6500K | 5100 | 2835 | 322 | 50W | 1500 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-050-UD-EM-AW-NW | 3800K-4200K | 5200 | ||||||||
| SC-SL8456-050-UD-EM-AW-WW | 2800K-3200K | 5000 | ||||||||
| SC-SL8456-080-UD-EM-AW-CW | 6000K-6500K | 8200 | 2835 | 504 | 80W | 2400 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-080-UD-EM-AW-NW | 3800K-4200K | 8400 | ||||||||
| SC-SL8456-080-UD-EM-AW-WW | 2800K-3200K | 8000 | ||||||||
| SC-SL8456-040-UD-(EM+DA)-AW-CW | 6000K-6500K | 4100 | 2835 | 252 | 40W | 1200 | 200-240VA C50/60Hz | >80 | 110° | Emergency + DALI dimming |
| SC-SL8456-040-UD-(EM+DA)-AW-NW | 3800K-4200K | 4200 | ||||||||
| SC-SL8456-040-UD-(EM+DA)-AW-WW | 2800K-3200K | 4000 | ||||||||
| SC-SL8456-050-UD-(EM+DA)-AW-CW | 6000K-6500K | 5100 | 2835 | 322 | 50W | 1500 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-050-UD-(EM+DA)-AW-NW | 3800K-4200K | 5200 | ||||||||
| SC-SL8456-050-UD-(EM+DA)-AW-WW | 2800K-3200K | 5000 | ||||||||
| SC-SL8456-080-UD-(EM+DA)-AW-CW | 6000K-6500K | 8200 | 2835 | 504 | 80W | 2400 | 200-240VA C50/60Hz | >80 | 110° | |
| SC-SL8456-080-UD-(EM+DA)-AW-NW | 3800K-4200K | 8400 | ||||||||
| SC-SL8456-080-UD-(EM+DA)-AW-WW | 2800K-3200K | 8000 |
