8860 Magnetic Seamless Connection Linear Light

SL8860 series is elegant architectural led linear light with Signcomplex patent design,10s quick continuous connection and various lens replacement,provides indirect/direct lighting distribution CCT/attage selectable,Suspended mount/ surface mount, or wall mount.

Quick magnetic seamlessly connection without any tools, more than 10 times faster than peers;
The indirect light module can be replaced, with various effects including PC cover, em bossed cover, lens (30°, 90°, single polarization, dual polarization), louver(50°, 50*50°, 35*75°), etc.;
Adjustable power, CCT, and up-down ratio (DOWN 100%/UP 30%+DOWN 70%/UP 50%+DOWN 50%/UP 50%) by dip switch;
Equipped with Y, T, L, + and other corner accessories;
Compatible with PIR induction and emergency program.

Inquire

Specifications

Download

Parameters

Model	Length	CCT	Lumen(lm±10%)	Power(w) (±10%)	Light Effect	Beam(angle)	UGR	LED Type	Voltage	CRI
SL8860UD-25-AW-A02-01SE	2FT	3000K-4000K-5000K	1650lm/2200lm/2750lm	15/20/25W	110lm/w	120°	/	2835	100-277VAC 50/60Hz	≥80
SL8860UD-50-AW-A02-01SE	4FT	3000K-4000K-5000K	3300m/4400lm/5500lm	30/40/50W
SL8860UD-100-AW-A02-01SE	8FT	3000K-4000K-5000K	6600lm/8800lm/11000lm	60/80/100W
SL8860UD-25-AW-A02-11SE	2FT	3000K-4000K-5000K	1950lm/2600lm/3250lm	15/20/25W	130lm/w	80°	<22
SL8860UD-50-AW-A02-11SE	4FT	3000K-4000K-5000K	3900lm/5200m/6500lm	30/40/50W
SL8860UD-100-AW-A02-11SE	8FT	3000K-4000K-5000K	7800lm/10400m/13000lm	60/80/100W
