Cibay-H2 Series High Bay Light

Cibay-H2 Series High Bay Light

  • Built in power supply, ultra-thin design, reduce 50% freight.

  • Plug&play sensor, like Motion sensor, PIR, Daylight sensor and Bluetooth are available.

  • Power adjustable, with Dip switch, it is easy to select.

  • CCT adjustable , two-color LEDs are equally spaced and symmetrically distributed,with uniform color mixing.

  • High efficiency LED, 140lm/w、160lm/w、180lm/w、200lm/w multiple brightness are levels is optional.

  • UV-resistant PC material optics, IK08 impact resistance grade.

  • Working temperature: -30 ℃ ~ + 50 ℃.

  • Suitable for damp environment, slight corrosion-proof grade indoors.

Inquire
Inquire
Share
Share
Specifications

Parameters

Model

CCT

Lumen(lm)±10%

Beam(angle)
  ±10%

LEDs type

CRI

Power(W)±10%

Voltage
Frequency

Type
CBH2-T100-AH-60K-D401/D411/D421

5500-6500K

13700

120° /90° /60°

SMD 2835

>80

100W

AH: 220-240VAC
50-60Hz, Max0.6A
140LM/W,
Power Adjustable,
CCT+Power Adjustable
CBH2-T100-AH-50K-D401/D411/D421

4700-5300K

14000
CBH2-T100-AH-40K-D401/D411/D421

3700-4300K

13800
CBH2-T100-AH-30K-D401/D411/D421

2700-3200K

13000
CBH2-T150-AH-60K-D401/D411/D421

5500-6500K

20550

120° /90° /60°

SMD 2835

>80

150W

AHW: 220-240VAC
           50-60Hz, Max0.85A

CBH2-T150-AH-50K-D401/D411/D421

4700-5300K

21000
CBH2-T150-AH-40K-D401/D411/D421

3700-4300K

20700
CBH2-T150-AH-30K-D401/0411/D421

2700-3200K

19500
CBH2-T200-AH-60K-D401/D411/D421

5500-6500K

27400

120° /90° /60°

SMD 2835

>80

200W

AW: 220-240VAC
50-60Hz, Max1.2A

CBH2-T200-AH-50K-D401/D411/D421

4700-5300K

28000
CBH2-T200-AH-40K-D401/D411/D421

3700-4300K

27600
CBH2-T200-AH-30K-D401/D411/D421

2700-3200K

26000
CBH2-T100-AH-60K-D601/D611/D621

5500-6500K

15700

120° /90° /60°

SMD 2835

>80

100W

AH: 220-240VAC
50-60Hz, Max0.6A
160LM/W,
Power Adjustable,
CCT+Power Adjustable
CBH2-T100-AH-50K-D601/D611/D621

4700-5300K

16000
CBH2-T100-AH-40K-D601/D611/D621

3700-4300K

15800
CBH2-T100-AH-30K-D601/D611/D621

2700-3200K

15000
CBH2-T150-AH-60K-D601/D611/D621

5500-6500K

23550

120° /90° /60°

SMD 2835

>80

150W

AHW: 220-240VAC
50-60Hz, Max0.85A

CBH2-T150-AH-50K-D601/D611/D621

4700-5300K

24000
CBH2-T150-AH-40K-D601/D611/D621

3700-4300K

23700
CBH2-T150-AH-30K-D601/D611/D621

2700-3200K

22500
CBH2-T200-AH-60K-D601/D611/D621

5500-6500K

31400

120° /90° /60°

SMD 2835

>80

200W

AW: 220-240VAC
50-60Hz, Max1.2A

CBH2-T200-AH-50K-D601/D611/D621

4700-5300K

32000
CBH2-T200-AH-40K-D601/D611/D621

3700-4300K

31600
CBH2-T200-AH-30K-D601/D611/D621

2700-3200K

30000
CBH2-T100-AH-60K-D801/D811/D821

5500-6500K

17500

120° /90° /60°

SMD 2835

>70

100W

AH: 220-240VAC
50-60Hz, Max0.6A
180LM/W,
Power Adjustable,
CCT+Power Adjustable
CBH2-T100-AH-50K-D801/D811/D821

4700-5300K

17800
CBH2-T100-AH-40K-D801/D811/D821

3700-4300K

17600
CBH2-T100-AH-30K-D801/D811/D821

2700-3200K

16800
CBH2-T150-AH-60K-D801/D811/D821

5500-6500K

26250

120° /90° /60°

SMD 2835

>70

150W

AHW: 220-240VAC
50-60Hz, Max0.85A

CBH2-T150-AH-50K-D801/D811/D821

4700-5300K

26700
CBH2-T150-AH-40K-D801/D811/D821

3700-4300K

26400
CBH2-T150-AH-30K-D801/D811/D821

2700-3200K

25200
CBH2-T200-AH-60K-D801/D811/D821

5500-6500K

35000

120° /90° /60°

SMD 2835

>70

200W

AW: 220-240VAC
50-60Hz, Max1.2A

CBH2-T200-AH-50K-D801/D811/D821

4700-5300K

35600
CBH2-T200-AH-40K-D801/D811/D821

3700-4300K

35200
CBH2-T200-AH-30K-D801/D811/D821

2700-3200K

33600
CBH2-T100-AH-60K-DA01/DA11/DA21

5500-6500K

19200

120° /90° /60°

SMD 2835

>70

100W

AH: 220-240VAC
50-60Hz, Max0.6A
200LM/W,
Power Adjustable,
CCT+Power Adjustable
CBH2-T100-AH-50K-DA01/DA11/DA21

4700-5300K

19500
CBH2-T100-AH-40K-DA01/DA11/DA21

3700-4300K

19300
CBH2-T100-AH-30K-DA01/DA11/DA21

2700-3200K

18500
CBH2-T150-AH-60K-DA01/DA11/DA21

5500-6500K

28800

120° /90° /60°

SMD 2835

>70

150W

AHW: 220-240VAC
50-60Hz, Max0.85A

CBH2-T150-AH-50K-DA01/DA11/DA21

4700-5300K

29250
CBH2-T150-AH-40K-DA01/DA11/DA21

3700-4300K

28950
CBH2-T150-AH-30K-DA01/DA11/DA21

2700-3200K

27750
CBH2-T200-AH-60K-DA01/DA11/DA21

5500-6500K

38400

120° /90° /60°

SMD 2835

>70

200W

AW: 220-240VAC
50-60Hz, Max1.2A

CBH2-T200-AH-50K-DA01/DA11/DA21

4700-5300K

39000
CBH2-T200-AH-40K-DA01/DA11/DA21

3700-4300K

38600
CBH2-T200-AH-30K-DA01/DA11/DA21

2700-3200K

37000

Size
