Ultra-thin Downlight DL102

Ultra-thin Downlight DL102

  • Adopt aluminum alloy as material, casting process,heat dissipation is good.

  • PC diffuser mask is adopted to give uniform light.

  • High light transmittance, low light loss, anti chord light.

  • Separate design of power supply and main body, which is more advantageous to ensure the life of power supply and LED.

  • The lamp is installed by snap type, which is faster.

Inquire
Inquire
Share
Share
Specifications
Download

Parameters

ModelCCTLumen(lm)LED TypeBeam angelPowerVoltage(V)/FrequencyCRIPF
±10%
Ultra-thin Downlight DL101
2.5inch
3000K749COB110°7W220-240VAC
50/60Hz
Ra>80>0.9
4000K757
5000K756
6500K780
Ultra-thin Downlight DL101
3.5inch
3000K1130COB110°10W220-240VAC
50/60Hz
Ra>80>0.9
4000K1053
5000K1064
6500K1095
Ultra-thin Downlight DL101
5inch
3000K1598COB110°15W220-240VAC
50/60Hz
Ra>80>0.9
4000K1743
5000K1756
6500K1765
Ultra-thin Downlight DL101
8inch
3000K3480COB110°30W220-240VAC
50/60Hz
Ra>80>0.9
4000K3590
5000K3548
6500K3560


Size

Ultra-thin Downlight DL102
