IP65 Waterproof Downlight

IP65 Waterproof Downlight

  • IP65 waterproof structure, you can install it to most wet location, like outdoor corridor, bathroom, ceiling of pookpak, saunas etc.

  • UGR<19, anti-glare design to efficiently reduce glare and create comfortable lighting environment

  • Good heat dissipation with aluminum alloy body, led feet temperature lower than 80° and improving the lamp service life.

  • High output COB led, led spectrum excluding infrared ray and uv to protect the illuminated objects

IP65 Waterproof Downlight
Inquire
Inquire
Share
Share
Specifications
Download

Parameters

ModelCCT

Lumen(lm)

±10%

LEDTypePower(W)Voltage(V)/FrequencyBeam angleUGRCRI
3RDL65-015-R830K-013000K1260lmCOB15W220-240V AC
50/60Hz
60°<19>80
3RDL65-015-R840K-014000K1360lm
3RDL65-015-R850K-015000K1420lm
4RDL65-020-R830K-013000K1800lmCOB20W220-240V AC
50/60Hz
60°<19>80
4RDL65-020-R840K-014000K1820lm
4RDL65-020-R850K-015000K1840lm
6RDL65-030-R830K-013000K2740lmCOB30W220-240V AC
50/60Hz
60°<19>80
6RDL65-030-R840K-014000K3100lm
6RDL65-030-R850K-015000K2920lm
8RDL65-040-R830K-013000K3790lmCOB40W220-240V AC
50/60Hz
60°<19>80
8RDL65-040-R840K-014000K4210lm
8RDL65-040-R850K-015000K4060lm


Size
