This downlight adopts exposed dip switch to adjust 5CCT so as to achieve the diversity of application.
Achieve selection of five types of color temperature through five-section dip switches.
Long service life: the adoption of LEDs ensures that the service life exceeds 50000 hours.
The adoption of optical engine design ensures higher integration and smaller volume.
Adopt DOB solution, the electromagnetic radiation is small.
Compatible with most dimmers of North American to obtain good dimming effect.
Dimming range: 10-100%.
| Model | CCT | Lumen(lm) ±10% | LED type | Power(W) | Voltage(V)/frequency | Max. pcs/dimmer | Work temperature |
| HTB4-010-AL-5CCT-01BD HTB4-010-AL-5CCT-01D | 2700K | 740 | Warm white: 2835*14 Cold white: 2835*14 | 10W | 120VAC 60Hz | 10pcs | -20℃~40℃ |
| 3000K | 810 | ||||||
| 3500K | 827 | ||||||
| 4000K | 860 | ||||||
| 5000K | 790 | ||||||
| HTB6-015-AL-5CCT-01BD HTB6-015-AL-5CCT-01D | 2700K | 1100 | Warm white: 2835*15 Cold white: 2835*15 | 15W | 120VAC 60Hz | 10pcs | -20℃~40℃ |
| 3000K | 1200 | ||||||
| 3500K | 1250 | ||||||
| 4000K | 1300 | ||||||
| 5000K | 1150 | ||||||
| HML6-015-AL-5CCT-01BD | 2700K | 950 | Warm white: 2835*15 Cold white: 2835*15 | 15W | 120VAC 60Hz | 6pcs | -20℃~40℃ |
| 3000K | 1100 | ||||||
| 3500K | 1200 | ||||||
| 4000K | 1250 | ||||||
| 5000K | 1100 |
